HFL3530

HFL3530是常州科魯奇軸承有限公司主營產品之一,憑借可靠的質量,穩定的性能,合理的價格,深受好評,廠家足貨供應,請來此了解詳情,采購請聯系13584568637.

13584568637

在線客服

客服一

產品詳情

軸徑 Shaft Diameter	軸承型號 BearingDesignation		重量Mass 近似Approx	外形尺寸 Boundary Dimensions			傳動力矩 Pemissible Torque Md	極限轉速 Limiting Speed		適用的沖壓外圈滾針軸 Suitable Drawn Cup Bearings
軸徑 Shaft Diameter	塑料簧片 Plastic Reed	304不銹鋼簧片 304 Stainless Steel Reed	重量Mass 近似Approx	FW	D	C	傳動力矩 Pemissible Torque Md	軸旋轉 Rotating Shaft Min-1	外圈旋轉 Rotatng Outer Ring Min-1
mm	塑料簧片 Plastic Reed	304不銹鋼簧片 304 Stainless Steel Reed	g	mm	mm	mm	N.m	軸旋轉 Rotating Shaft Min-1	外圈旋轉 Rotatng Outer Ring Min-1
3	HF0305KF		0.9	3	6.5	5	0.2
3	HF0306KF		0.9	3	6.5	6	0.2	36000	7000	HK0306TN
4	HF0406KF	HF0406	1	4	8	6	0.34	34000	8000	HK0408TN
4	HF0406KFR	HF0406R	1	4	8	6	0.34	34000	8000	HF0408TN
6	HF0608KFR	HF0608	2	6	10	8	1	20000	11000	HK0608
	HF0610KF	HF0610	2.8	6	10	10	1.5	20000	11000	HK0608
	HF0612KF	HF0612	3	6	10	12	1.76	23000	13000	HK0608
	HF0612KFR	HF0612R	3	6	10	12	1.76	23000	13000	HK0608
		HF061210	3.5	6	12	10	3	20000	13000	HK061208
8	HF0812KF	HF0812	3.5	8	12	12	3.15	17000	12000	HK0808
	HF0812KFR	HF0812R	3.5	8	12	12	3.15	17000	12000	HK0808
		HF081210	3.2	8	12	10	3	16000	12000	HK0808
		HF081410	3.6	8	14	10	4.6	15000	11000	HK081410
		HF081412	4	8	14	12	5	16000	12000	HK101410
10	HF1012KF	HF1012	4	10	14	12	5.3	14000	110000	HK1010
10	HF1012KFR	HF1012R	4	10	14	12	5.3	1400	11000	HK1010
12	HF1216R	HF1216	11	12	18	16	12.2	11000	8000	HK1212
14	HF1416R	HF1416	13	14	20	16	17.3	9500	8000	HK1412
16	HF1616R	HF1616	14	16	22	16	20.5	8500	7500	HK1612
18	HF1816R	HF1816	16	18	24	16	24.1	7500	7500	HK1812
20	HF2016R	HF2016	17	20	26	16	28.5	7000	6500	HK2010
25	HF2520R	HF2520	30	25	32	20	66	5500	5500	HK2512
30	HF3020R	HF3020	36	30	37	20	90	4500	4500	HK3012
35	-	HF3520	40	35	42	20	121	3900	3900	HK3512
